Complex façades.Precisely resolved.

Field measurement, shop drawings, CNC machining and installation for ACM and metal façades.

See how we work
White ACM folded around the corner of a building, with a soffit grid below Perforated ACM sheet seen at an angle against the sky Perforated screen inside a white ACM frame Long ACM band above the glazing and over a soffit Orange folded pieces on perforated sheets Faceted ACM panels beside a yellow returned frame
01 / 06

Corner

A folded corner

White ACM wraps the corner in one fold. The sheets meet on a clean line, and the soffit grid sits right underneath.

Photography from the field.

The project

Now open it, piece by piece

Loading model
Drag to orbit · scroll to zoom · hover a piece · click to open it
1 / 4
Project shown: Perforated sheets in rice shape.

One plan behind every panel.Continuity of information between the field condition and the machine.

From field measurement to installed façade.

Technical package or full delivery, with single-point responsibility.

351pieces, each identified
3,120sq ft of ACM sheets (290 m²)
49aluminum structure frames
3elevations clad, plus a soffit

Figures taken from the model above.
